CYT1002AE 單段LED線性恒流恒功率控制芯片

CYT1002AE is a single segment LED linear constantcurrent control chip with constant power and highpower factor. It integrates 700V high voltage MOSFET,with superior resistance to avalanche breakdown a...
  • CYT1002AE
  • 品  牌:CYT
  • 參考價:1       庫 存:99999
  • 產品描述:

    CYT1002AE is a single segment LED linear constantcurrent control chip with constant power and highpower factor. It integrates 700V high voltage MOSFET,with superior resistance to avalanche breakdown andsurge. It can pass 700V lightning surge test when noprotection device in the periphery, and built-in over-temperature protection function to improve systemapplication reliability. The output current can beadjusted by adjusting the REXT on the periphery. Atthe same time, the CYT1002AE integrates the inputline voltage compensation function. When the inputline voltage is too high, CYT1002AE will reduce theoutput current according to the external compensationresistor to ensure that the input power does notchange with the line voltage.It is mainly used in the fields of LED lighting,architectural lighting engineering, etc. The systemstructure is simple, the peripheral components are few,the PCB traces are simple, and the solution cost islow.

    Input voltage: 120Vac/220Vac

    Support high PF solution: PF>0.9

    Support low PF solution: PF>0.5, no flicker

    Output current bias between ICs<±5% Integrated 700V high-voltage MOS tube, can pass 700V lightning strike without any protection device

    No magnetic components for EMI applications

    With over temperature adjustment

    With constant power regulation

    Package: ESOP8

    Applications

    LED fluorescent tube T5/T8

    LED bulb

    Projection lamp

    Mining lamp

    LED lamp
